Wall Jado
Our surface-mounted range of LED wall lights is perfectly suited for a variety of outdoor lighting applications. These luminaires are designed to illuminate both the wall surface and the area in front of it, making them ideal for providing subtle accents on vertical surfaces.

Product Description
• Luminaire body made of GI frame fixed and non corrosive SS fasteners.
• Non yellowing UV stabilized clear acrylic diffuser.
• Pressure die-cast aluminium base for easy installation onto the wall.
• Surface mounting on wall using hardware after connecting to the power supply.
• Cable entries for through-wiring of mains supply cable.
• Integral constant current power supply
• CRI (Ra) : =80
• Prewired with LED driver and suitable for operating on 240V, 50Hz single phase ac supply.
• Ordering guide : KL-24211-CCT (Colour Temperature)
• Available CCT : 2700K, 3000K, 4000K, 5700K

Product Benefits
• High luminous efficiency at reduced wattage.
• Quick installation and low assembly costs.
• Dark sky compliant protects pedestrians from glare by preventing spill light above the horizontal plane.

Area of Application
Residential, Building facade, Commercial centres, Passages, Pathways, Sculptures and Structures.

Available Finish
Pure polyester powder coated
RAL 9004 Black
RAL 9007 Grey aluminium
RAL 7016 Anthracite grey
Graphite grey

Special Finish - On Request
Teak
Bamboo
IDWattageDimensionMounting IESPhotometryTechnical DatasheetTechnical Description
KL-421112W LED 2700K,3000K,4000K,5700K, Clear Acrylic205 x 86 x 251mmW28
Detailed Foundation Drawing
KL-4211-BA--WW.IES
KL-4211-BA--CW.IES
KL-4211-BA--NW.IES
KL-4211-BA--WW.PDF
KL-4211-BA--CW.PDF
KL-4211-BA--NW.PDF
4211.pdf
KL-4211.txt
